DS-171
DS
DS-171
DMX512/ DMX512/AUTO
indoor use
14.5KG
480pcs 5050 0.5W RGB 3in1 LEDs
Carton or Flightcase
1000w
9CH / 18CH / 64CH / 82CH
8/16 bits
aluminum
2years
Features & Specifications:
•LED Type: 5050 0.5W RGB 3in1 LEDs
•LED Count: 480
•LED Colors: RGB
•LED Segments: 16 (2 x 8)
•LED Type: 3535 5W 6500K/2700K/2700K-6500K LEDs
•LED Count: 144
•LED Colors: Cool-White/amber/white and amber
•LED Segments: 8
Movement
•Resolution: 8-16 Bit
•Tilt (Degrees): 185°
Control
•Control Modes: 9CH / 18CH / 64CH / 82CH
•Display: Illuminated graphic LCD
•Protocol: USITT DMX-512, RDM,ART-NET
•RDM: Bidirectional communication
•Cooling: Temperature controlled, overheating protection
Effects
•Dimmer: 0-100% electronic
•Shutter: electronic, max. 20 Hz
•Internal Effects: LED Macro Effects
•Signal connection: IP20 XLR 5-Pin or 3-Pin In/Out
•Power Input: PowerCON TRUE1 In/Out
Operating Conditions
•Mains voltage: 100-240V AC / 50-60Hz
Power: 1000W
•Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F
Mounting Options
•Hanging: Omega-Bracket
•Safety wire attachment: foldout eyelets
Shipping
•Single fixture: cardboard
•Tourpack: 4-way Flight Case
Housing Colors
•Standard colors: black
Features & Specifications:
•LED Type: 5050 0.5W RGB 3in1 LEDs
•LED Count: 480
•LED Colors: RGB
•LED Segments: 16 (2 x 8)
•LED Type: 3535 5W 6500K/2700K/2700K-6500K LEDs
•LED Count: 144
•LED Colors: Cool-White/amber/white and amber
•LED Segments: 8
Movement
•Resolution: 8-16 Bit
•Tilt (Degrees): 185°
Control
•Control Modes: 9CH / 18CH / 64CH / 82CH
•Display: Illuminated graphic LCD
•Protocol: USITT DMX-512, RDM,ART-NET
•RDM: Bidirectional communication
•Cooling: Temperature controlled, overheating protection
Effects
•Dimmer: 0-100% electronic
•Shutter: electronic, max. 20 Hz
•Internal Effects: LED Macro Effects
•Signal connection: IP20 XLR 5-Pin or 3-Pin In/Out
•Power Input: PowerCON TRUE1 In/Out
Operating Conditions
•Mains voltage: 100-240V AC / 50-60Hz
Power: 1000W
•Maximum ambient temperature: -30°C / 86°F, 50°C / 122°F
Mounting Options
•Hanging: Omega-Bracket
•Safety wire attachment: foldout eyelets
Shipping
•Single fixture: cardboard
•Tourpack: 4-way Flight Case
Housing Colors
•Standard colors: black
