12x10W RGBW Beam LED Moving Head Light

  • DS-76
  • DS
  • DS-76
  • 12x10W 4 IN 1 LED Moving Head
  • 46x33.5x38.5cm
  • CPL
  • Guangzhou
  • Carton or Flightcase
  • 0-100%
  • 11/15 DMX channels
  • 120-240V 50-60HZ
  • 12 degree
  • IP22
Features& Specifications:
12x10W RGBW 4 IN 1 LED Moving Head Light
Voltage: AC90-240V, 50/60Hz
Watts:   180W
Source: the 12 American CREE MC-E 4 in 1 series LED
Lifespan: 100000 hours
Color: RGBW four-color (12Pcs 4in1)
Lens: 12 degree beam lens
Counting positioning system: double optical coupler, dual Holzer positioning
Driving mode: LED using constant current driver, Motor driven by mute
Control mode: the international standard DMX512, Auto Program, master-slave control
Channel mode: 11/15 channel
Cooling method: using high thermal conductivity aluminum PCB, The high thermal
 conductivity aluminum, cooling fan, over-temperature protection
PAN / TILT: X630 /Y 240 degree, fast running speed, Adjustable speed.
Dimmer: 0-100% linear dimming
Strobe: 1-25 / sec
Display: LCD display
Working environment: indoor, -15 to 40 degree
• DMX, stand-alone, master/slave, sound activated mode
• DMX recorder and edit function integrated
• 3-pin or 5-Pin XLR serial input/output
• Fan cooling system
• 2 x 1/4 turn fastening Omega Clamps
• Electronic ballast and power supply
IP rating: IP20
Net Weight: 5kg
Dimension: 304x267x167mm
