500W LED Framing CMY CTO

Availability:
Quantity:
  • DS-53
  • DS
  • DS-53
  • DMX512
  • Indoor Use
  • 36kg
  • 500W
  • Carton or Flightcase
  • 550w Max.
  • 32/36 channelsDMX channels USITT DMX-512
  • 8000K CRI>95
  • Zoom range:6°-53°
  • 2 years


Features&Specifications:

•Light Sources: Powerful 500W LED engine

•LED life expectancy: 20000 hours

•Advanced optical system to ensure image quality, clear and sharp

•High - efficiency optical system

•Beam Angle: 6°-53°

•Prism: one 4-facet rotation prism

•Brightness: 5M@86000Lux

•4-buttons touch panel

•Display: Color display

•Protocols: DMX512, RDM, Art-Net(optional)

•DMX Protocol modes: 2 modes

•Control channels: 32/41 Chs

•Pan/Tilt Resolution: 16 bit

•Firmware Upgrade: Upgrade via DMX link

•Pan movement: 540°

•Tilt movement: 270°

•Fixation: Tilt lock

•Automatic Pan/Tilt position correction

•1 x rotating gobos with 7 gobos, convenient replacement

•Static Gobos

•1 x static gobos with 8 gobos

•1 x color wheel with 5 colors

•Linear CMY & CTO

•Framing shutters: 4x framing shutters, each individually controllable

•Each shutter blade can block out light completely

•Movement is fast, smooth and precise, with adjustable speed

•Each shutter blade can block out light completely

•Framing module can be rotated at ±45°

•Power supply with electronic auto-ranging

•Input voltage range: 100-240V~ 50/60Hz

•Power consumption: 700 W

•Power Connector in/out,3-pin and 5-pin XLR connector in/out

•Dimensions:400*400*690mm

•Gross weight: 36kg

•Net Weight:32kg

•Packing size:49x41x78cm

• With Flodable Clamps
