DS-1198
DS
DS-1198
DMX512
outdoor use
43.4kg
1400W
Carton or Flightcase
1400W
36/42CH
4 kinds of curve dimmer
5°-50° linear zoom
2years
Features&Specifications:
•Voltage:AC100-240V 50/60Hz
•Light source:1500W/1200W LED
•Rated lifetime:≥20000Hours
•CRI:High CRI Mode Ra≥90, Ra≥75(Optional), In addition, you can choose a high CRI source with Ra≥95
•Zooming angle: 5°-55°
•Framing:4 groups and eight directions of blade, full crossover of each blade, the framing system can rotate 90° and each blade can shape Individually and cut off
•Static gobo wheel:8 static gobos + open
•Rotating gobo wheel: 7 interchangeable gobos + open
•Animation wheel: dynamic effect like flame or water, etc
•Color Wheel: 5 colors+open
•CTO:Independent CTO, color temperature can be linear adjusted (2800K-7800K)
•CMY:Linear CMY, with linear color chang, limitless color mixing
•Pan/tilt: 540°/270°, 16-bit control and automatic return correction
•Prism:4 facet prism,4 linear prism
•Focus: High-precision glass lenses, electronic linear HD focus
•Iris: Linear 5-100%, with built-in macros
•Dimmer: 0-100% linear electronic dimming
•Strobe: 1-30Hz, synchronized, pulse effects
•Frost:Two frosts, light frost and heavy frost
•Channel:36CH/42CH
•Display:LCD display
•Software: Update software by DMX connection
•Control mode: DMX 512, RDM, Artnet(Optional), Auto-running , Master/slave, Sound active, Built-in program
•IP class: IP66
•Net weight:37kg
•Gross weight:43.4kg
•Packing size:95.5*60.5*47.5CM
•1 in 1 flightcase, with
• Foldable Clamps
