18x15W RDM Wireless LED Wall Washer

2.4G Wireless, IP65, Touch Screen, 15W RGBW LEDs, Small body with 13.5KG, Multi DMX modes, 4 dimming modes
Availability:
Quantity:
  • DS-100

  • DS

  • DS-100

  • DMX512/ WDMX

  • Outdoor use

  • 2.4inches TFT display operation

  • 15W RGBW

  • Carton or Flightcase

  • 250

  • 6 DMX Modes:2/3_1/3_2/4/12/14/26CH

  • 4 kinds of curve dimmer

  • 10°/25°/45° Beam Angle

  • 9.4kg



Specifications
•Rated Voltage:AC100V~240V 50-60HZ
•Rated Power:250W
•LED Qty:18x15W High power RGBW LEDs
•LED Drive Current: 1A
•Beam Angle: 10°/25°/45°
•6 Kinds of DMX modes:3/4_1/4_2/5/15/20/21/37CH
•Dimmer mode: 2 kinds
•IP Class: IP65
•DMX Mode:2/3_1/3_2/4/12/14/26CH
•Packing Size:450x345x250 mm
•Net weight:8.2Kg
•Gross weight:9.4Kg

Product Features
•Dmx input:3 pin electronic J3F2C-W
•Dmx output:3 pin electronic K3F2C-W
•Power connection:electronic powerCON in(SAC3MPX)/ powerCON
 out(SAC3FPX)
•3 kinds of control model: DMX512,WDMX,Master/slave.
•2.4G Wireless DMX control.
•Setting and Addressing:RDM
•Software update:Update via DMX link
•DMXfunction:Dimmer,Strobe,RGBW,Macro color,Color jump,Color
 fade,Rainbow,Auto Program choice,Auto speed,Curve dimmer
 select,Function setting
•Stand-alone mode: Color step,Color shade,Auto,Slave,Macro color,Static
 color setting, Rainbow,Auto program choice
•Housing:aluminium
•Housing color:Black
•2.4inch TFT color display screen
•High anti-jamming four-button touch keys
•Operation temperature:-20°C~+40°C .
•7 Kinds of DMX modes: 2/3_1/3_2/4/12/14/26CH.
•Dimmer:0-100%and 16Bit dimmer
•Dimmer mode: 2 kinds
•Refresh rate:800Hz/1200Hz/2000Hz/3600Hz /25KHz optional
•4 kinds of curve dimmer:Linear Dimmer、Square Dimmer、I. Square Dimmer、
 S-Curve Dimmer
•Display board can be 180°in turn,it can be fitted in different setting.
•Strobe effect:Plus Random、Ramp up Random、Ramp down Random、
 Random strobe、Strobe Break Effect,5s......1s、Strobe 0-20Hz.
•Perfect mixing color and rainbow effect
•Cooling system:fan cooling(Auto&high-speed)
