• Rated VoltageAC100V~240V 50-60HZ • Rated consumption:250W • LED Qty: 240W RGBW LED • LED drive current :2.5A • Beam angle:4-50°Zoom • IP Class :IP65 • DMX mode :3CH/4CH/6/12CH mode • Packing Size:400x320x540mm • N.W:9.2KG • G.W:10.0KG
Product Features • DMX input:3-pin SeetronicJ3F2C-W • DMXoutput :3-pin SeetronicK3F2C-W • Power connect:Seetronic powerCON IN (SAC3MPX) / OUT (SAC3FPX) •Setting and addressing:RDM •Software update :Update via DMX link • DMX function :dimmer 、strobe、RGBW、macro,color jumping 、color gradual changes、dimmer curve selection、function setting • Stand-alone:color jump、color gradual changes、Auto、Master-slave、Macro、static color setting 、Auto selection • Housing material:aluminium alloy • Housing color:black • 1.3 inch OLED display •High anti-interference four touch buttons • Display board can be 180°overturn • Operating temperature:-20°C~+40°C • 4 kinds of DMX mode:3CH/4CH/6/12CH mode • Dimmer :16bit • Dimmer mode :2 kinds of •Dimmer frequency selection:800/1200/2000/3600/25K Hz • Perfect color mixing effect • All colors can be total dimmer • Fan dissipation (the fan will change the speed with the temperature changes) • 4 kinds of dimmer curve:Linear Dimmer、Square Dimmer、I. Square Dimmer、S-Curve Dimmer。 • Strobe effect :Pulse Random、Ramp up Random、Ramp down Random、Random strobe、 Strobe Break Effect, 5s…..1s、Strobe0-20Hz
Specifications:
• Rated VoltageAC100V~240V 50-60HZ • Rated consumption:250W • LED Qty: 240W RGBW LED • LED drive current :2.5A • Beam angle:4-50°Zoom • IP Class :IP65 • DMX mode :3CH/4CH/6/12CH mode • Packing Size:400x320x540mm • N.W:9.2KG • G.W:10.0KG
Product Features • DMX input:3-pin SeetronicJ3F2C-W • DMXoutput :3-pin SeetronicK3F2C-W • Power connect:Seetronic powerCON IN (SAC3MPX) / OUT (SAC3FPX) •Setting and addressing:RDM •Software update :Update via DMX link • DMX function :dimmer 、strobe、RGBW、macro,color jumping 、color gradual changes、dimmer curve selection、function setting • Stand-alone:color jump、color gradual changes、Auto、Master-slave、Macro、static color setting 、Auto selection • Housing material:aluminium alloy • Housing color:black • 1.3 inch OLED display •High anti-interference four touch buttons • Display board can be 180°overturn • Operating temperature:-20°C~+40°C • 4 kinds of DMX mode:3CH/4CH/6/12CH mode • Dimmer :16bit • Dimmer mode :2 kinds of •Dimmer frequency selection:800/1200/2000/3600/25K Hz • Perfect color mixing effect • All colors can be total dimmer • Fan dissipation (the fan will change the speed with the temperature changes) • 4 kinds of dimmer curve:Linear Dimmer、Square Dimmer、I. Square Dimmer、S-Curve Dimmer。 • Strobe effect :Pulse Random、Ramp up Random、Ramp down Random、Random strobe、 Strobe Break Effect, 5s…..1s、Strobe0-20Hz
